Baja Designs

S1 Black Flush Mount Auxiliary Light Pod

S1 Black Flush Mount Auxiliary Light Pod

380001
$129.95 USD
$129.95 USD
Sale Sold out
Shipping calculated at checkout.

Designed from the ground up our new S1 fills the shoes of a large light in a small package! The S1 utilizes a highly specialized reflector and LED combination to put 2,320 raw lumens down range. With the 2.1 inch length, width, and height the S1 is highly versatile for any application that is in need of light. Whether you're looking for a light to drive off of, or something to light up a campsite the S1 will exceed your expectations!

Brightness

 Lumens Amperage Rating
2,320 1.42A

Dimensions

Depth in. Height in. Length in. Weight lbs.
2.10
 2.10 2.10 0.4

Detailed Specs

Average Rated Life (hr.)

49,930

Available Beam Patterns

Spot, Wide Cornering, Work Scene

Bezel Material

Hard Anodized and Powder Coated Cast Aluminum

Housing Color

Black

Housing Material

Aircraft Grade Aluminum with Mil-Spec Hard Anodize

Available Lens Colors

Clear

Lighting Modes

Beam

Lens Material

Hard Coated Polycarbonate

Lighting Type

LED

Hardware Included

Yes

Hardware Material

Stainless Steel

Overvoltage Protection

Built-In

Wiring Harness Included

No



Durability

Exceeds MIL-STD810G (Mil-Spec Testing)

Water Resistance

IK10 Compliant (Mechanical Impact Testing)

Impact Resistance

IP69K (Waterproof up to 9ft & Pressure Washable)



Satisfaction Guarantee – 30-Day Money Back Guarantee

Limited Lifetime Warranty – Complete Purchase Protection

uService – Replaceable Lenses And Optics

ClearView – All The Light, Right Where You Need It

MoistureBlock – Waterproof, Rain Proof, Submersible

CopperDrive – Only LED Driven At 100 Percent

5000K Daylight – Less Driver Fatigue, Natural Color


VEHICLE LIGHTING ZONES
The needs of every off-roader are different, so we've created a Lighting Zone system to help you mix and match the right products, with the right lenses, in the right places to achieve the absolute best results.
Learn more about each zone's placement, power, and pattern.

Learn more

View full details

Lens Patterns:

  • Wide Cornering

    The Wide Driving pattern offers a 42-degree flattened horizontal beam for the ultimate in comfort lighting. This pattern is specifically for cornering, dust, snow, rain, and/or fog conditions.

  • Driving Combo

    Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42-degree) and spot (9-degree) optics to provide you with a smooth blend of light for both near field applications and distance.

  • Spot

    A longer and narrower 9-degree beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights.

  • Work/Scene

    Excellent work light or “scene light” with an extremely smooth 120° circle that projects about 40ft. This pattern is not suitable for driving.
