Baja Designs

RTL-M Spare Tire Mount Kit w/ Light

RTL-M Spare Tire Mount Kit w/ Light

447795
$370.95 USD
$370.95 USD
Sale Sold out
Shipping calculated at checkout.

This Spare Tire Mount allows for quick and easy mounting of the Baja Designs RTL-M. The Spare Tire Mount was designed to sit near the center of the wheel on a rear-facing spare tire carrier. Designed around a Jeep JK, the mount picks up two lug nut locations on the factory spare tire mount - though it will work with any 5x127 mm pattern carrier. All necessary hardware is provided with each kit.

Baja Designs 447795 Installation Sheet

Brightness

Lumens Amperage Rating
312
        --

Dimensions-RTL-M

Depth in. Height in. Length in. Weight lbs.
2.5 1.56 6.69 1.1

Detailed Specs

Application RTL-M Lights
Bracket Material Stainless Steel
Description Spare Tire Mount w/ Light
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Product Type RTL-M Spare Tire Mount Kit w/ Light



Durability

Exceeds MIL-STD810G (Mil-Spec Testing)

Water Resistance

IK10 Compliant (Mechanical Impact Testing)

Impact Resistance

IP69K (Waterproof up to 9ft & Pressure Washable)



Satisfaction Guarantee – 30-Day Money Back Guarantee

Limited Lifetime Warranty – Complete Purchase Protection

uService – Replaceable Lenses And Optics

ClearView – All The Light, Right Where You Need It

MoistureBlock – Waterproof, Rain Proof, Submersible

CopperDrive – Only LED Driven At 100 Percent

5000K Daylight – Less Driver Fatigue, Natural Color


VEHICLE LIGHTING ZONES
The needs of every off-roader are different, so we've created a Lighting Zone system to help you mix and match the right products, with the right lenses, in the right places to achieve the absolute best results.
Learn more about each zone's placement, power, and pattern.

Learn more

View full details

Lens Patterns:

  • Wide Cornering

    The Wide Driving pattern offers a 42-degree flattened horizontal beam for the ultimate in comfort lighting. This pattern is specifically for cornering, dust, snow, rain, and/or fog conditions.

  • Driving Combo

    Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42-degree) and spot (9-degree) optics to provide you with a smooth blend of light for both near field applications and distance.

  • Spot

    A longer and narrower 9-degree beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights.

  • Work/Scene

    Excellent work light or “scene light” with an extremely smooth 120° circle that projects about 40ft. This pattern is not suitable for driving.
